MAS SPU 20 MC
Location:Brno, Czech Republic
Description
Equipment:
Axes S1 / C1 / S2 / C2 / S3 / X / Y / Z / B / U / W
Fixed and rotating tool holders and tools
Specifications
| Manufacturer | MAS |
| Model | SPU 20 MC |
| Year | 1996 |
| Condition | Used |
| Stock Number | 4918 |
| Control system | SIEMENS SIN 840 C |
| Turning diameter over bed (max) | 600 mm |
| Turning diameter over cross slide (max) | 260-500 mm |
| Maximum power of the main spindle | 22 kW |
| Minimum rotary speed of the main spindle | 40 1/min |
| Maximum rotary speed of the main spindle | 5000 1/min |
| Workpiece weight | 50 kg |
| Number of tool head positions | 12 |
| Spindle drilling | 77 mm |
| Max. bar diameter | 65 mm |
| Distance between spindles | 998 mm |
| Subspindle power | 23 kW |
| Maximum subspindle speed | 6000 1/min |
| Length of the lathe | 3590 mm |
| Width of the lathe | 1600 mm |
| Height of the lathe | 2050 mm |
| Weight | 6900 kg |
