HAAS MINIMILL HE
Location:Brno, Czech Republic
Specifications
| Manufacturer | HAAS |
| Model | MINIMILL HE |
| Year | 2006 |
| Condition | Used |
| Stock Number | 8854 |
| Control system | HAAS |
| Hours on | 23434 h |
| Length of the working table | 914 mm |
| Width of the working table | 305 mm |
| Maximum table load (evenly distributed) | 227 kg |
| Power of the spindle drive | 7.5 kW |
| Maximum rotary speed of the vertical spindle | 6000 1/min |
| X-Axis travels | 406 mm |
| Y-Axis travels | 326 mm |
| Z-Axis travels | 381 mm |
| Taper | ISO 40 |
| Maximum number of tools | 10 pcs |
| Machine height | 2565 mm |
| Machine length | 2119 mm |
| Machine width | 2077 mm |
| Machine weight | 2018 kg |
| 2024 | spindle bearing remeasured |
| 2023 | Y-axis thrust bearing replaced |
| 2022 | spindle runout measured |
| 2018 | Z-spindle feed bearing replaced and motor clutch replaced |
