Model |
VDL500 |
VDL600 |
VDL1000A |
VDL1000 |
VDL1200 |
VDL1400 |
Table size(L x W) (mm) |
700x320 |
800x400 |
1220x460 |
1120x560 |
1120x620 |
1600x630 |
T-slot(Nos x width x CD) (mm) |
3x14x100 |
3x18x130 |
5x18x80 |
5x18x100 |
5x18x100 |
5x18x120 |
Max.Load on table (kg) |
150 |
500 |
800 |
750 |
1200 |
1500 |
Distance from spindle center to column way surface (mm) |
430 |
460 |
520 |
629 |
660 |
760 |
Distance from spindle nose to table (mm) |
150-530 |
150-690 |
100-730 |
135-735 |
100-775 |
140-840 |
X/Y/Z travel (mm) |
450/350/380 |
600/400/540 |
1000/500/630 |
1020/560/600 |
1200/600/675 |
1400/650/700 |
X/Y/Z guideway type (m/min) |
Linear way |
Linear way |
Linear way |
X&Y Linear way/Z box way |
X&Y Linear way/Z box way |
Linear way |
X/Y/Z rapid traverse speed (mm/min) |
36/36/36 |
20/20/15 |
30/30/24 |
24/24/18 |
24/24/28 |
24/24/24 |
Feedrate (mm/min) |
1-10000 |
1-5000 |
1-10000 |
1-10000 |
1-10000 |
1-8000 |
X/Y/Z servo motor power (Nm) |
3/3/6 |
12/12/22 |
12/12/12 |
12/12/12 |
12/12/12 |
22/22/22 |
Spindle motor power (kW) |
3.7/5.5 |
7.5 |
7.5/11 |
7.5/11 |
11/15 |
15/18.5 |
Spindle speed range (r/min) |
60-8000 |
37.5-5000(8000) |
18-7500 |
60-8000 |
45-6000 |
45-6000 |
Spindle taper |
#40(7/24) |
#40(7/24) |
#40(7/24) |
#40(7/24) |
#50(7/24) |
#50(7/24) |
Tool magazine capacity/type |
drum |
drum |
swing arm |
drum |
swing arm |
swing arm |
Tool shank type |
BT40 |
BT40 |
BT40 |
BT40 |
BT50 |
BT50 |
Max.Tool weight (kg) |
5 |
7 |
7 |
7 |
15 |
15 |
Max.Tool diameter/length (mm) |
ø89/250 |
ø100/250 |
ø75/250 |
ø100/305 |
ø127/305 |
ø110/350 |
Time of tool change(T-T) (Sec) |
6-8 |
6-8 |
3 |
6-8 |
3.5 |
5 |
Way of tool change |
optional |
optional |
standard accessories |
optional |
standard accessories |
standard accessories |
Positioning accuracy (mm) |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
Repeatibility (mm) |
±0.003 |
±0.003 |
±0.003 |
±0.003 |
±0.003 |
±0.003 |
CNC control system |
FANUC 0i-M |
FANUC 0i-M |
FANUC 0i-M |
FANUC 0i-M/MELDAS M64 |
FANUC 0i-M/MELDAS M64 |
FANUC 0i-M |
Required air (kg/cm2) |
5 |
5 |
5 |
6 |
6 |
6 |
Power requirements (KVA) |
12 |
20 |
35 |
25 |
35 |
50 |
Overall dimension(L x W x H) (mm) |
2450x1700x2200 |
2320x2510x2770 |
3500x3200x3000 |
2530x2820x2500 |
2880x2815x2770 |
4510x3520x3640 |
Net weight (kg) |
2000 |
6000 |
7000 |
7000 |
8500 |
10000 |
|
